G2 Nonwoven Air Filter Replacement Prefilter

G2 Nonwoven Air Filter Replacement Prefilter
Request a Quote

The G2 nonwoven air filter replacement prefilter is used primarily for filtering floating particles that are larger than 5 microns. These filters are primarily used in air conditioner preliminary filtering, and pre filtering treatment for multistage filtering systems.

Parameter
Filter classification Size (mm) L*W*H Rated air flow quantity (m³/h) Initial resistance (Pa) Filter efficiency Outer frame Filter element Protective cover
G2 595×595×46 3200 25 65% Paper Aluminum alloy galvanized sheet G2 non-woven sheet Galvanized mesh
595×495×46 2700
595×295×46 1600
495×495×46 2200
295×295×46 800
Features
  • The air filter features large air flow quantity, maximum air flow quantity up to 3200 m³/h
  • Aluminum alloy and galvanized sheet frame, produced in a plate structure for easy cleaning and replacement.
  • Using a G2 non-woven cloth filter material, the air filter is both washable and reusable, thus lowering costs.
