Indoor LED Screen 500*500mm Rental LED Cabinet

Indoor LED Screen          500*500mm Rental LED Cabinet
Indoor LED Screen          500*500mm Rental LED Cabinet
Request a Quote
Features:
  • The cabinet is ultra-thin, lightweight (8kg) and easy to assemble and disassemble.
  • Applying special heat dissipation structures. Because there is no fan, there is no noise and it can reduce power consumption.
  • Using high standard technology, so there is no obvious seam between cabinets, resulting in high-impact visuals.
  • High refresh rate and stable image, without flicker.
  • The SMT technology has been used with its clearer, sharper HD images and high brightness from any distance.
  • Applying brightness and chroma correction technology, and color depth processing technology with an aim to color consistency.
Parameters:
Model P2.97 P3.91 P4.81
Pixel Pitch 2.97mm 3.91mm 4.81mm
Pixel Configuration SMD 1R1G1B SMD 1R1G1B SMD 1R1G1B
LED Type 2020 2020 2020
Pixel Per SQM 112,896 dots 65,536 dots 43,264 dots
Module Size 250x250mm 250x250mm 250x250mm
Module Resolution 84x84 dots 64x64 dots 52x52 dots
Cabinet Size 500x500 mm 500x500 mm 500x500 mm
Cabinet Resolution 168x168 dots 128x128 dots 104x104 dots
Cabinet Material Die-casting Aluminum Die-casting Aluminum Die-casting Aluminum
Cabinet Weight 8kg 8kg 8kg
Brightness 1200 cd/m2 1200 cd/m2 1200 cd/m2
Viewing Angle 120 / 120 degree 120 / 120 degree 120 / 120 degree
Driving Method 1/21 1/16 1/13
Minimum Viewing Distance 3m 4m 5m
Gray Scale 65,536 65,536 65,536
Refresh Rate 1920 Hz 1920 Hz 1920 Hz
Input Voltage (AC) 100v - 240v 100v - 240v 100v - 240v
LED Blind Spot Rate 1/10,000 1/10,000 1/10,000
Lifetime 100,000 h 100,000 h 100,000 h
Operating Temperature -25 ~ 40 ℃ -25 ~ 40 ℃ -25 ~ 40 ℃
Operating Humidity 10% - 90% 10% - 90% 10% - 90%
Protection Rate IP31 IP31 IP31
Warranty 3 years 3 years 3 years
