Features:
  • Applying modular die-casting aluminum cabinet, ultra-lightweight, ultra-thin, and easy to transport, installation and disassembly.
  • Refresh rate up to 3840Hz, gray scale processing level up to 16bit, contrast up to 5,000:1, clear and true display picture quality, bright and smooth playback effect.
  • Adopting high- brightness LEDs and brightness can reach more than 4500cd/m2. The picture is still clearly visible in the sunlight.
  • The stripe design of the mask has been precisely calculated, which greatly reduces the problem of LED device caused by the reflection of ambient light. And we ensure that the contrast of the product is optimal in various environments, so the color of the image is restored more truthfully.
  • Applying thermal conductive silicone irrigation on the front, the back protection with silicone conformal coating, and double waterproof protection, so that LED display is more weather-resistant, better heat dissipation.
  • Seamless assembly technology: Cabinet and module gap tolerance control in 0.1mm, screen flat splicing distance control in the 0.1mm.
Parameters:
Model P3.91 P4.81 P5.95
Pixel Pitch 3.91mm 4.81mm 5.95mm
Pixel Configuration SMD 1R1G1B SMD 1R1G1B SMD 1R1G1B
LED Type 1921 2727 2727
Pixel Per SQM 65,536 dots 43,264 dots 28,224 dots
Module Size 250x250mm 250x250mm 250x250mm
Module Resolution 64x64 52x52 42x42
Cabinet Size 500x500mm 500x500mm 500x500mm
Cabinet Resolution 128x128 104x104 84x84
Cabinet Material Die-casting Aluminum Die-casting Aluminum Die-casting Aluminum
Cabinet Weight 8.5kg 8.5kg 8.5kg
Brightness 4500 cd/m2 5000 cd/m2 5000 cd/m2
Viewing Angle 120 / 120 ° 120 / 120 ° 120 / 120 °
Driving Method 1/16 1/13 1/7
Minimum Viewing Distance 4m 5m 6m
Gray Scale 65,536 65,536 65,536
Refresh Rate 1920 Hz 1920 Hz 1920 Hz
Input Voltage (AC) 100v - 240v 100v - 240v 100v - 240v
Frame Frequency 50 or 60 Hz 50 or 60 Hz 50 or 60 Hz
LED Blind Spot Rate 1/10,000 1/10,000 1/10,000
Lifetime 100,000 hours 100,000 hours 100,000 hours
Operating Temperature -25 ~ 40 ℃ -25 ~ 40 ℃ -25 ~ 40 ℃
Operating Humidity 10% - 90% 10% - 90% 10% - 90%
Protection Rate IP65 IP65 IP65
Warranty 3 years 3 years 3 years
