CO2 laser Marker, RF CO2 Laser
Request a Quote
CO2 laser marker is designed for marking non-metallic materials including marking production date on food and beverage packaging, marking logo on ceramic surface. It also can be used for cutting and hollow carving very thin materials such as cardboard, board, leather, etc.
This machine use RF laser tube. Width of slit made by RF laser will be narrower because the optical quality of the beam is better, giving a finer focus spot.
Applicable materials:
Wooden product, paper, leather, cloth, denim, plexiglass, epoxy resin, acrylic, unsaturated polyester resin, etc.
- This CO2 laser marker use Windows interface and compatible with output files of popular software including AutoCAD, Coreldraw, Photoshop, etc.
- This machine supports various file formats like PLT, PCX, DXF, BMP, SHX, TTF, etc. It has auto-coding, graphic reverse printing and automatic jump number function. It can mark serial number, batch number, date, bar code, QR code, etc.
- This CO2 laser marker can be used in production lines and automated production line.
| Model | CMT-10 / CMT30 /CMT-60 |
| Laser type | CO2 RF tube |
| Laser power（W） | 10W/30W/60W |
| Marking scope（mm） | 100*100, 200*200 , 300*300 |
| Marking speed | ≤8000mm |
| Minimum character | 0.4mm |
| Marking depth | ≤5MM |
| Repeat position accuracy | ±0.01MM |
| Cooling type | Air/water cooling system |
| Acceptable graphic format | PLT, DST, AI, DXF, BMP, JPG, CAD, CDR, DWG |
| Operating voltage | AC 110/220V±10%, 50/60Hz |
| Operating temperature range | 10-35 ℃ |
| Operating humidity | < 75%( non-condensing water) |
| Dimensions | 950*900*1600mm |
| Machine power | < 1250W |
| IP rating | IP54 |
| Laser safety class | Class IV |
