Injection Mold for Bucket

Buckets have a flow path length and wall thickness ratio of 300 to 1, requiring that a mold be made with exceptional precision. We use the concept of a water lines layout to design thin walled molds, in a production process that takes as little as 24 seconds.

Project:8L Bucket Country: UK
Brand: NA Product: Bucket
Material: PP Steel: XPM
Cavity:1 Gating solution:1 Drop YUDO Hot runner with hot tip
Mold dimension:850*650*780 Product dimension:265.7*265.7*244.5
Injection machine:800 T
