Introduction

The JH36 closed type power press machine uses multi-link drive with two kinds of modes: slow processing and fast return.

Parameters
Model JH36-110 JH36-160 JH36-200 JH36-250 JH36-315 JH36-400 JH36-500 JH36-630

Nominal pressure KN
1100 1600 2000 2500 3150 4000 5000 6300

Nominal pressure stroke
5 3 6 3 7 4 7 4 8 8 10 10
Stroke of slide mm 180 110 200 130 230 150 250 180 250 250 280 300
S.P.M
stroke
35~65 45~80 30~50 35~65 25~45 30~55 20~40 30~50 23~35 20~35 18~25 15~25

Max. die set height mm
400 435 450 485 500 540 550 585 550 550 580 600

Die Height Adjustment mm
90 100 110 120 120 120 120 120
Distance Between Uprights mm 1750 1970 2200 2400 2600 2750 2900 3100

Bottom Size of Slide
Width mm
L-R
1360 1500 1850 2000 2100 2300 2400 2600
Length mm
F-B
520 580 650 700 750 800 850 1100
Size of Table Width mm
L-R
1700 1930 2100 2300 2400 2700 2850 3000
Length mm
F-B
680 760 840 920 950 1000 1200 1400

L-Side Openings
Height mm
UP and Down
500 500 600 600 600 600 700 700
Length mm
F-B
600 750 800 900 900 900 1000 1000

Overall dimension Of the puncher
Width mm
L-R
2350 2600 3050 3350 3550 3800 3950 4000
Length mm
F-B
1950 2370 2500 2650 2700 2800 3600 3900
Height mm
Height
3530 3900 4400 4900 5200 5300 5750 6100

Main Motor Power (kw)
15 22 22 30 37 37 45 55
(Please enter your desired product model)
Features
  • The two-point quick return of press increases the production efficiency by about 30% when compared to traditional crank presses.
  • The press has a high precision and meets the first class JIS standards.
  • The machine uses welding technology and has a high rigidity.
  • The press uses a long guide rail with eight sides to ensure the accuracy. The JH36-110U JH36-160 model uses a six-sided guide rail.
  • A dry-type pneumatic friction clutch is required so that the clutch can easily engage or separate from power, and the clutch will not overheat during short periods of time in a semi-clutch state.
  • Hydraulic overload protection function with high sensitivity protects the machine from being severely damaged due to incorrect operation.
  • The lubricating oil can be automatically added to this power press machine, so the machine is not easy to be worn.
  • The machine uses frequency conversion and frequency modulation to ensure machine operation accuracy as well as an excellent stability.
  • PLC centralized control makes user operation easy.
  • The equipment can be customized according to customer needs, including an output shaft, air cushion, sliding block feeding, automatic feeding and other devices.
