700M Metric Bolts, DIN 7643
Request a Quote
Application: for use with hydraulic braided hoses
Materials:- Stainless steel metric bolts, DIN 7643
- Carbon steel metric bolts, DIN 7643
| Part No. | Tube O.D. | Dimensions | ||||
| A | B | C | S1 | |||
| 700M-10 | M10×1 | 19 | 4 | 6 | 17 | |
| 700M-12 | M12×1.5 | 24 | 6 | 6 | 17 | |
| 700M-14 | M14×1.5 | 26 | 8 | 7 | 19 | |
| 700M-16 | M16×1.5 | 28 | 9 | 7.5 | 22 | |
| 700M-18 | M18×1.5 | 32 | 11 | 8 | 24 | |
| 700M-22 | M22×1.5 | 39 | 14 | 9 | 27 | |
| 700M-26 | M26×1.5 | 45 | 18 | 10 | 32 | |
| 700M-30 | M30×1.5 | 51 | 22 | 11 | 38 | |
