710M Metric Bolts, JB Standard
Request a Quote
Application: for use with hydraulic braided hoses
Materials:- Stainless steel metric bolts, JB standard
- Carbon steel metric bolts, JB standard
| Part No. | Thread | Dimensions | ||||
| E | A | B | C | S1 | ||
| 710M-10 | M10×1 | 25 | 4 | 6 | 17 | |
| 710M-14 | M14×1.5 | 32 | 8 | 7 | 19 | |
| 710M-18 | M18×1.5 | 38 | 11 | 8 | 24 | |
| 710M-22 | M22×1.5 | 48 | 14 | 9 | 30 | |
| 710M-27 | M27×2 | 60 | 18 | 10 | 36 | |
| 710M-33 | M33×2 | 63 | 22 | 12 | 41 | |
| 710M-42 | M42×2 | 85 | 28 | 14 | 55 | |
