XHHW-2 Aluminum Cable

XHHW-2 Aluminum Cable
Request a Quote

XHHW-2 aluminum cable has a compact stranded AA-8000 series aluminum alloy conductor with cross-linked polyethylene (XLPE) insulation. It has good resistance against sunlight, abrasion, water and heat.

Cross-linked polyethylene high heat-resistant water-resistant wire is to be used at conductor temperatures up to 90℃ in dry, damp or wet locations. The voltage rating is 600 volts. The cable can be installed without using pulling lubricant.

Applications:

Aluminum XHHW-2 cable is commonly used in conduits, feeder and branch circuits as specified in the NEC and for health care facilities according to Section 517.160 of the NEC where a dielectric constant less than 3.5 is required.

Standards:

Our XHHW-2 cable meets the requirements of UL 44. It has passed the following tests: current overload test, FT2 horizontal flame test, 720h sunlight resistance test, aging test on insulation materials, dielectric voltage withstand test, etc.

Specifications:

Conductor Size (AWG or kcmil)

Nominal Cond. Diameter

Insulation Thickness

Nominal Thickness

Approx. Weight

Allowable Ampacities
Inch mm mils mm mils mm Kg/Km LBS/1000FT 60℃ 75℃ 90℃
8 0.134 3.4 45 1.14 224 5.7 19 13 35 40 45
6 0.169 4.29 45 1.14 259 6.6 22 15 40 50 55
4 0.213 5.41 45 1.14 303 7.7 27 18 55 65 75
2 0.268 6.81 45 1.14 358 9.1 33 22 75 90 100
1 0.299 7.59 55 1.4 409 10.4 45 30 85 100 115
1/0 0.336 8.53 55 1.4 446 11.3 49 33 100 120 135
2/0 0.376 9.55 55 1.4 486 12.4 54 36 115 135 150
3/0 0.423 10.74 55 1.4 533 13.5 59 40 130 155 175
4/0 0.475 12.07 55 1.4 585 14.9 66 44 150 180 205
250 0.520 13.21 65 1.65 650 16.5 84 56 170 205 230
300 0.570 14.48 65 1.65 700 17.8 91 61 195 230 260
350 0.616 15.65 65 1.65 746 19.0 97 65 210 250 280
400 0.659 16.74 65 1.65 789 20.0 102 69 225 270 305
500 0.736 18.69 65 1.65 865 22.0 112 75 260 310 350
600 0.813 20.65 80 2.03 973 24.7 153 103 285 340 385
700 0.877 22.28 80 2.03 1037 26.3 163 110 315 375 425
750 0.908 23.06 80 2.03 1068 27.1 168 113 320 385 435
900 0.999 25.37 80 2.03 1159 29.4 181 122 355 425 480
1000 1.060 26.92 80 2.03 1220 31.0 189 127 375 445 500
