Fabric Cutting Machine (Bias Cutter)
Bias Cutter/ Fabric Cutter/ Tape Cutter
Technical Parameters:
1. The fabric cutting machine is mainly used for the v-belt tape cutting process during production, the machine completes length cutting and winding reels of tape.
2. PLC control, servo driven, the photodetector greatly improves cloth-cutting machine performance.
3. Rated cloth width: 1200mm
4. Rated cutting width: MAX: 200mm (DBC-200mm)
MAX:750mm (DBC750mm)
5. Cutting precision: ±1mm
It’s the experimental typical precision, varies with change of rubberized fabric quality.
6. Speed of cutting , splicing and curling :12times/min or above (typical speed of cutting and splicing 500mm rubberized fabric, changed with qualification of operator and width of fabric.)
7. Cutting method: round knife cutting.
8. Cutting angle: 45°
